4

ISM/SRD

RFID

RFW-D100

■ Simple to operate link manager

■ Provides parallel interface to the MCU

■ Input/output FIFO’s

RFW-NC

■ Designed especially for low end

applications – ultra low cost, easy

& convenient integration into

applications, small outline

■ Data rate of up to 1 Mbps

■ Frequency agility – supports 5 diffe-

rent operating channels

■ Operating frequency: 2.4GHz - world

wide unlicensed band

RFW3M / RFW8M

■ High Data rate – up to 3 Mbps/8 Mbps

■ Frequency agility – supports 7/5

different operating channels, each

channel utilizes DSSS with a unique

spreading code

■ Operating frequency: 2.4 GHz –

world-wide unlicensed band

RFW3M-PA

■ Designed for extended range wireless

communication in the 2.4 GHz –

world-wide license free ISM band

■ High Data rate – up to 3 Mbps

■

Frequency agility – supports 5 diffe-

rent operating channels, each channel

utilizes DSSS, with a unique spreading

code

RFW122-M

■ Ultra low power RF transceiver

■ Operating frequency: 2.4 GHz –

world-wide unlicensed band

■ Data rate – up to 1Mb per second

RFW122-M-PA

■ Enhanced range RF transceiver – up

to 40 meters indoors communication

range

■ Operating frequency: 2.4 GHz –

world-wide unlicensed band

■ Data rate – up to 1Mb per second

Active RFID

■

Operates in the 2.4 GHz ISM band

■ Tag with controller, RF transceiver and

battery

■ Addresses up to 200 tags per second

■ Unique ID for each tag

+ 20 characters editable

■ Up to 50 m range, all directions,

with standard antenna

■ Tag battery life time up to several

years

■ Communicates via RS232, RS422,

Bluetooth, LAN, WLAN

■ Tag available with temperature

sensor (optional)

■ Customizing of tags possible

■ Start kit available
